4-37
4.3
Control element
4
Function Description
4.3.8
Communications interfaces
Communications interfaces
4-
4.3.8.1
RS 232 interface
RS 232 interface
4-
][Funktion_RS_232_protego_D
The servo amplifier has an RS 232 interface with minimum configuration
(TxD, RxD, GND):
`
Using the commissioning software, you can use the RS 232 interface
to set the following parameters on a PC:
– Operating parameters
– Position control parameters
– Motion block parameters
`
The interface is selected and set-up in the commissioning software.
For further information please refer to the chapter entitled “Wiring”.
4.3.8.2
CANopen interface
CANopen interface
4-
][Funktion_CANopen_protego_D
The servo amplifier has a CANopen interface for connection to a bus
system:
The interface uses the following profiles:
`
CANopen communication profile, specification CiA DS-301
`
Device profile for drives DS-402.
The following functions are available for position controllers, for exam-
ple:
`
Jogging with variable speed
`
Reference runs
`
Start motion task
`
Start direct motion task
`
Specify digital setpoint
`
Data transfer functions
For further information please refer to the CANopen manual.
When the appropriate parameters are set, the analogue setpoint inputs
can still be used.
