SiteSync IQ Installation Manual
Remote Connect Web Interface
Glossary
Appendix
Tr
oubleshooting
Clock
Installation
System Contr
oller
Installation
Intr
oduction
The Remote Connect Web Interface allows remote access to your SiteSync IQ system controller via a web browser. This includes Event
and Circuit programming, manual circuit activation, time/date settings and other system configurations.
This feature is available to all SiteSync IQ System Controllers with the Ethernet option.
Note: Java SE Runtime Environment (JRE) 7 Update 7 will need to be installed to run the Events Applet.
–This can also be downloaded at http://www.java.com/en/
–Ensure that you have the most current web browser (ie. Firefox, Internet Explorer, Chrome)
To access Remote Connect:
1. Ensure that the SiteSync IQ System Controller installation has been performed (page 6) and that the Ethernet option has been
configured (pages 18-19)
2. Open a web browser. Enter the IP address for your system controller (#4 on page 18) as http://xxx.xxx.xxx.xxx or ssiq plus last
six digits of MAC address if DHCP is Enabled in the web browser’s Address field (Figure 1). Press the
Enter key.
or
Figure 1
n
Note: If using DHCP Host Name, the network or computer connected to the system controller for configuration must be on the same
Subnet for Host Name to work properly.
n
Note: If the Remote Transmitter is on a network without a DHCP server, the default address of the Remote Transmitter will be
192.168.10.10. In this situation, directly connect an Ethernet patch cable from the Remote Transmitter to a computer that is on the same
Subnet. Example: Set the connecting computer IP address to 192.168.10.11. See your Network Administrator if you do not know how to
do this.
3. A User Login window, (Figure 2) will appear. There are two available user names,
uclock and sclock, which represent the user
and service access levels. The user security level allows access to everything but the Configuration Tab.
User Level Access:
Enter
uclock in lowercase letters in the User Name field and uclock in the Password field. This is a user login which will allow
access to time/date and event menus.
Service Level Access:
Enter
sclock in lowercase letters in the User Name field and sclock in the Password field. This is a service login which will
allow access to all menus.
**Passwords may be changed in the Configuration Tab.
Then, click the Login button.
Figure 2
4. The Remote Connect utility will appear with the General tab selected. The tabs displayed may differ depending on the
configuration of the unit.
Figure 3
For more details on the features of Remote Connect, click on the Support link in the upper right-hand corner of the utility (Figure 3).
