14
The LED will change colour depending on the operating status
(1) LED steady green:
-
Comes on after the FRONIUS IG’s automatic start-up phase and stays on as long
as power is being fed into the mains
- The photovoltaic system is working correctly
(2) LED flashing green:
-
The photovoltaic system is working correctly
- A message also appears on the display
NOTE! A message will appear if, for instance, there is an insulation fault even if
it does not have any adverse effect on the FRONIUS IG’s operation. However,
our advice is that, for safety reasons, the insulation fault is rectified as soon as
possible.
A status message is displayed. If a message such as “502”! is displayed (see chapter
entitled “Status diagnosis and repair”), the status concerned should be rectified and the
“Enter” key then pressed in confirmation.
(3) LED steady orange:
-
The FRONIUS IG will enter its automatic startup phase as soon after sunrise as the
photovoltaic modules are delivering sufficient power
(4) LED flashing orange:
-
A warning appears on the display
- Or the FRONIUS IG has been switched to standby mode in the setup menu = power
feed-in is switched off manually
- Power feed-in is resumed automatically after the next sunrise
- When the orange LED is flashing, power feed-in can be started manually at any time
(see chapter entitled “The Setup Menu”)
(5) LED steady red:
-
General status: The relevant service code is shown on the display
A list of service codes, corresponding status messages, and causes and remedies for
particular statuses can be found in the chapter entitled “Status diagnosis and repair” in
the installation and service instructions.
(6) LED remains dark:
-
No connection to solar modules
- No output from module due to absence of daylight
LED for opera-
ting status
Status LEDs on
the power modu-
les (1) LED flashing green:
-
The power module is in the startup phase
(2) LED steady green:
-
The power module is in feed-in mode
(3) LED remains dark:
-
No slave is required due to the low level of insolation
