MDE-4331M Atlas® Fuel Systems Installation Manual · September 2014
Page A-19
Foundation Diagrams
Atlas Diagrams
Figure A-18: Model 9850KXTW1 - UHF Dispenser (TWIN 1)
7.02
178
[
]
7.02
178
[
]
6.30
160
[
]
6.30
160
[
]
9.82
249
[
]
5.47
139
[
]
15.70
399
[
]
28.41
722
[
]
7.85
199
[
]
14.21
361
[
]
11.8
298,46
[
]
5.5
140,24
[
]
2.37
60,229
[
]
9.64
244,914
[
]
7.32
186,000
[
]
2.37
60,238
[
]
9.64
244,790
[
]
2.18
55,356
[
]
6.19
157,173
[
]
1/2-inch NPT Conduit
Connection Optional
DC Application
2-inch NPT Product Inlet
Anchor Bolt Slots
(Use 1 minimum each side)
1-1/2-inch NPT Discharge to
Satellite
1-1/2-inch NPT
Discharge to
Satellite
Footprint
AC Power
Connection
Product Inlet
Discharge to Satellite
Model 9850KXTW1
1-inch NPT Conduit
Connection AC
Power
Side 1 Nozzle
Boot (Side Load
Units)
Side 1 Nozzle Boot (Front
Load Units)
