Console Port
AS56 and AS56
Plus
User Manual
A-7
Console Port
The Access Syst em56 Console Port allows the user to connect to an
external terminal. The port provides a DE-9 receptacle.
SUPV Port
(DB-9)
DCE
1
DCD out
2
RXD out
3
TXD in
4
DTR in (not used)
5
signal groun
6
DSR out
7
RTS in
8
CTS out
9
RI out (not used
