Basic Speed Control Output Instance 70 (46 Hex)
This function is the basic I/O instance of Assembly Object Class (04 Hex) Attribute (03 Hex), which defines DeviceNet AC
Drive Profile. Both input/output use 4 bytes each.
Table 14: Drive Basic Speed Control Instance 70 (46 Hex) (OUTPUT ASSEMBLY)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
-
-
-
-
-
During FWD
Run (Fwd)
-
Fault
1
-
-
-
-
-
-
-
-
2
Speed Monitor (Lower Byte)
3
Speed Monitor (Upper Byte)
Data
Name
Description
Byte 0, Bit 0
Fault
The drive fault detection status is displayed. 0: Normal
1: During fault detection
Byte 0, Bit 2
During FWD
The drive run status is displayed.
0: During Stop/REV.
1: During FWD/DC braking
Byte 2, 3
Speed Monitor
The drive speed is displayed.
Speed monitor data: Frequency monitor [r/min]×1/2
SS
where
SS
: Speed Scale
*1
Example: If speed monitor data is 1000RPM (03E8 Hex), speed scale = 0
Lower Byte (byte 2) = E8 Hex, Upper Byte (byte 3) = 03 Hex
Frequency monitor: 03E8 Hex X 1/2
0
X = 1000r/min.
Note: *1 Speed scale can be set by explicit messages communication AC/DC Drive Object (Class 2A Hex) attribute 16.
*2 When applying a speed reference make sure to set No. of poles (2 ~ 39) to the drive parameter o1-03 (frequency reference set/display unit
selection).
