Features, Getting started unpacking – Solid State Logic SSL 12 USB Audio Interface User Manual
Page 2
SSL 12's capabilities are further extended with the power of SSL 360°; an
application hosted on your computer where the powerful SSL 12 Mixer page allows
for super low latency (sub 1 ms) headphone mixes, flexible loopback functionality
and customisation of the 3 user-assignable switches on the front panel. See the
SSL 360°
section for more information.
Features
4 x SSL-designed microphone preamps
with unrivalled EIN performance
and huge gain range for a USB-powered device
Per-Channel Legacy 4K switches
- analogue colour enhancement for any
input source, inspired by the 4000-series console
2 Hi-Z instrument inputs
for Guitars, Bass or Keyboards
2 professional-grade headphone outputs
, with plenty of power & switchable
options for high impedance or high sensitivity headphones.
32-bit / 192 kHz AD/DA Converters
- capture and hear all the detail of your
creations
ADAT IN
- expand the input channel count with up to 8 channels of digital
audio.
Easy-to-use
Headphone routing via SSL360°
for critical
low-latency
monitoring
tasks
Built In
Talkback Mic
that can be routed to Headphone A, B and Line 3-4
outputs
4 x balanced outputs
and precision Monitor Level, with stunning dynamic
range
Use Outputs 3-4 to connect an alternative monitor set to or as general
additional line-level outputs.
Headphone Outputs are switchable to Balanced Line Outputs
for
additional outputs.
DC-coupled outputs
for controlling CV input instruments & FX
3 user-assignable front panel switches
- assign to various monitoring
functions and talkback open/close
MIDI I/O
SSL Production Pack Software Bundle
: Includes the SSL Production Pack
Software Bundle - an exclusive collection of DAWs, Virtual Instruments and
Plug-ins
USB bus-powered audio interface for Mac/Windows - power is provided by
USB 3.0, audio via the USB 2.0 protocol
K-Lock Slot for securing your SSL 12
Getting Started
Unpacking
The unit has been carefully packed and inside the box you will find the following
items:
SSL 12
