Once the CV Utility Plug-In is Open, set the CV To to your designated Output.
In this example we've set this to Output 4 from the SSL 12 .
Set up a second Audio track with the input signal from the Effect/Instrument
and record arm to monitor the input back into Ableton Live.
Now using the
CV Value knob on the CV Control channel, you can automate
the CV signal sent out of Ableton to your External Instrument/FX unit. This can
then be mapped to a MIDI controller to control in realtime, or record the
Automation into your session.
Now you can record the audio back into your Ableton Session, or other DAW
you may be using to record your Audio back onto your system.
Please note that multiple CV Utility plugs can be set up when using the SSL 12
as
EVERY PHYSICAL OUTPUT is able to send DC signal for CV Control.
Therefore you can use up to 8 CV control signals at any one time using CV
Tools and an
SSL 12
Requirements for CV Tools
Live 10 Suite (version 10.1 or later)
Live 10 Standard + Max for Live (version 10.1 or later)
A DC-coupled audio interface (for CV hardware integration) such as the
SSL
12
Some understanding of Ableton Live Packs
Some understanding of how to use CV-enabled hardware with Live
Best Practices & Safety
Never send CV directly to your speakers. (Direct voltage can cause damage
to your speakers/hearing).
When Using Outputs
1/2, 5/6 & 7/8 , to allow for correct signal values ensure
the corresponding Volume knobs are turned fully Clockwise. The MONITOR
LEVEL controls the Level for
Outputs 1&2 , and the HP A & HP B knobs
control the levels for Outputs 5&6 & 7&8 respectively.
The CV Instrument device is only capable of calibrating oscillators that use
bipolar voltage (+/-5V) for 1v/oct. tuning. However, some digital oscillator
modules exclusively use unipolar signals (+5V or above) for tuning. As a
result, CV Tools will be incompatible with these modules. If you are unsure
whether this applies to the modules in your system, please consult the user
manual for the device.
Remember - Eurorack signals are up to 5x louder than line-level audio! Before
connecting your modular system to a digital audio interface, be sure to reduce
the signal down to line-level using a dedicated output module.
SSL USB Control Panel (Windows Only)
If you're working on Windows and have installed the USB Audio Driver required to
make the unit operational, you will have noticed that as part of the installation the
SSL USB Control Panel will be installed onto your computer. This Control Panel will
