133 User Guide
V1.1.0 Issue 1
15. Specifications
Mic/Line Inputs Balanced XLR, Balanced XLR/TRS Combi, fully recallable
preamp
Input Sensitivity -60 to +0dBu
Line Inputs (Combi Sockets) -20dB Pad (Fixed)
Hi-Z Inputs (CQ-20B 15&16) Relay switched, 1M Ohm impedance, 0 to +40dB gain
Analogue Gain 0dB to +60dB, 1dB steps
Maximum Input Level +17dBu (XLR), +30dBu (TRS)
Input Impedance >1.5kΩ (XLR), >10kΩ (TRS)
THD+N, Unity gain 0dB 0.002% -92dBu (20Hz-20kHz, USB soundcard, @0dBu 1kHz)
THD+N, Mid gain +30dB 0.004% -88dBu (20Hz-20kHz, USB soundcard, @-30dBu 1kHz)
Phantom Power +48V (+3V / -2V)
Stereo Line Inputs
Stereo Line Input Connection Balanced, 1/4" TRS Jack, Normalled
Input Sensitivity Nominal +4dBu
Trim +/-24dB
Maximum Input Level +21dBu
Input Impedance >10kΩ
Outputs
Main LR Balanced, XLR
Outputs 1-6 Balanced, 1/4" TRS Jack (CQ-18T, CQ-12T), XLR (CQ-20B)
Output Impedance <75Ω
Nominal Output +4dBu = 0dB meter reading
Maximum Output Level +22dBu
Residual Output Noise -88dBu (muted, 20Hz-20kHz)
