17 User Guide
V1.1.0 Issue 1
Connect using WiFi Access Point (CQ-18T, CQ-20B)
1) Navigate to CONFIG / CONTROL & NETWORK / Network
 If there is already a connection to the CQ-20B, otherwise follow First connection to a
CQ-20B .
2) Switch Enabled Network to WiFi Access Point
3) Setup the network. Recommended settings are:
• WPA2 Password on
• WPA2 Password set (change from default ‘DefaultPassword’)
• Frequency dependent on environment and other equipment
• Channel set to Auto
• SSID Hidden (once all devices have connected and stored network
details)
4) Note the network name and password.
5) Apply any changes.
6) Connect the remote device to the Wi-Fi network that ’ s just been set up.
7) Run CQ-MixPad or CQ4You and connect to the CQ from the Choose Unit
list.
 If the unit does not appear in the choose unit list, try selecting ‘Other’ and entering
the IP address manually. The current IP address of the unit is listed in the HOME /
SYSTEM / Info screen.
