Available Libraries
All Libraries are displayed as a pop-up, accessed using the Library button in the
screen listed in brackets here. Libraries affect the selected channel or processing
being viewed.
Whole Input Channel
(
CONFIG
/
INPUTS
)
Includes: Input name/colour, preamp/trim settings, Quick Channel or Complete
Channel (HPF, Gate, PEQ, Compressor)
Input Channel
Processing
(
PROCESSING
/
INPUTS
(
bank view
))
Includes: Quick Channel, Complete Channel (HPF, Gate, PEQ, Compressor)
Input Channel
Processing
(
PROCESSING
/
INPUT / Quick Channel
)
Includes: Quick Channel or Complete Channel (HPF, Gate, PEQ, Compressor)
Whole Output Channel
(
CONFIG
/
OUTPUTS
)
Includes: Output name, EQ Type, GEQ or PEQ+FBA, Compressor, Limiter
Output Channel Processing
(
PROCESSING
/
OUTPUTS
(
bank view
))
Includes: EQ Type, GEQ or PEQ+FBA, Compressor, Limiter
Gate
(
PROCESSING
/
INPUT
/
Gate
)
Includes: Gate settings only
GEQ
(
PROCESSING
/
OUTPUT
/
GEQ
)
Includes: GEQ settings only
PEQ
(
PROCESSING
/
INPUT
/
PEQ
and
PROCESSING
/
OUTPUT
/
PEQ
)
Includes: PEQ settings only
Feedback Assistant
(
PROCESSING
/
OUTPUT
/
FBA
)
Includes: FBA settings and Fixed Mode filters only
Compressor
(
PROCESSING
/
INPUT
/
Compressor
and
PROCESSING
/
OUTPUT
/
Compressor
)
Includes: PEQ settings only
Limiter
(
PROCESSING
/
OUTPUT
/
Limiter
)
Includes: Limiter settings only
FX
(
FX
)
Includes: FX model, FX parameters, FX Unit Mute Mode, Insert Mix%
