97 User Guide
V1.1.0 Issue 1
Sends to an Output
Touch Sends to and select an output to show all send levels to that output on the
fader for each input and FX channel.
With an Output other than Main LR selected, the fader background is coloured blue
to indicate that
fader positions are showing the ‘Sends to’ an output other than
Main LR.
 Only FX units in shared mode can be ‘Sent to’ MainLR, an Output or another FX Unit .
 Outputs cannot be sent to other Outputs, so their fader always controls their output
level.
When sending to a stereo output, pan controls are available, though if Follow Main
LR Pan is On for the selected output, the pan value is only displayed and cannot be
adjusted.
The RHS fader is used to control the overall send, or output level. This is a
duplicate of the output channel fader in the OUTPUTS bank view.
