Allen & Heath CQ-20B Ultracompact 20-Channel Digital Mixer (Rackmount/Stagebox) - Manual (Page 39)


39 User Guide
V1.1.0 Issue 1
Send multiple inputs to one output using the FADER screen
1. Go to the FADER screen and check that the fader
on the right- hand side is labelled ‘Main LR’. If not,
use the Sends to button to show all available ‘ Send
to ’ destinations and select Main LR .
2. Use the tabs at the top of the screen to navigate
between banks of Inputs.
3. Raise the fader for any Input (or multiple inputs) to
send signal from input channel to the Main LR
output. Touch/Click and drag, or select the fader
and use the Touchscreen rotary control (CQ-12T,
CQ-18T).
4 Adjust the (overall) Main LR output using the fader
on the right-hand side.
