Allen & Heath CQ-20B Ultracompact 20-Channel Digital Mixer (Rackmount/Stagebox) - Manual (Page 2)


2 User Guide
V1.1.0 Issue 1
1. Important Information .................................................................................. 7
2. Introduction ................................................................................................... 8
The different models .............................................................................................. 8
Images and examples in this guide ................................................................ 10
3. Updating Firmware ...................................................................................... 11
Update firmware using the CQ-MixPad app ................................................ 11
Update firmware using a USB drive ................................................................12
4. Connections .................................................................................................. 13
Power ........................................................................................................................... 13
1. Mic/Line Inputs ................................................................................................... 13
2. Outputs .................................................................................................................. 14
3. Footswitch ........................................................................................................... 14
4. USB and SD.......................................................................................................... 15
5. Network Port ....................................................................................................... 15
6. Built-In WiFi Access Point (CQ-18T, CQ-20B) ....................................... 15
5. Connecting control apps ......................................................................... 16
First connection to a CQ-20B ........................................................................... 16
Connect using WiFi Access Point (CQ-18T, CQ-20B)............................... 17
Connect using an external router or network ............................................ 18
Connect a computer directly with a network cable ................................ 18
6. Operation and Workflow ........................................................................... 19
Physical Controls (CQ-12T, CQ-18T) ............................................................... 19
CQ-MixPad ............................................................................................................... 20
CQ4You....................................................................................................................... 22
Workflow and main screens overview .......................................................... 23
