2. Introduction
Welcome to the CQ User Guide.
CQ is a range of portable, standalone digital audio mixers which use 96kHz
processing and include assistants and tools designed to be used by technical and
non-technical users alike.
There are 3 models in the range, two with hands-on control, and all of which can be
controlled remotely. All have a similar set of features and specifications, with
differences in I/O, channel count and control options.
The different models
Mic/Line
Inputs
5x XLR
5x ‘Combi’
XLR/TRS
8x XLR
8x ‘Combi’ XLR/
TRS
8x XLR
8 x ‘Combi’ XLR/
TRS
Stereo Line
Inputs
1 (2x Balanced TRS) 1 (2x Balanced TRS)
2 (4x Balanced
TRS)
Main Outputs 2x XLR 2x XLR 2x XLR
Monitor/Aux
Outputs
6x Mono
Balanced TRS
6x Mono
Balanced TRS
6x Mono
Balanced XLR
Headphone
Outputs
1x ¼” TRS 2 x ¼” TRS 1x ¼” TRS
Touchscreen 7” Multi-Touch 7” Multi -Touch
-
SoftKeys 3 3
-
Soft/Smart
Rotaries
- 3
-
FX Engines 2 4 4
