41 User Guide
V1.1.0 Issue 1
Send multiple inputs to one Output using the FADER screen
1. Go to the FADER screen and use the
Sends to button, above the fader on the
right-hand side, to select an output to
send signal to.
2. Use the tabs at the top of the screen to
navigate between banks of Inputs.
3. Raise the fader for any Input in order to
send signal from that input channel to the
selected Output.
Touch/Click and drag faders, or select the
fader and use the Touchscreen rotary
control (CQ-12T, CQ-18T).
4 Adjust the (overall) Output level using the
fader on the right-hand side.
 Repeat steps 2 to 4 for different inputs
and different outputs to set the mix for
each.
