84 User Guide
V1.1.0 Issue 1
Ratio – The ratio of the incoming signal to compressed signal when compression is
active. E.g. when set to 3:1 and when compressing, every 3dB increase in level at
the input will result in only a 1dB increase of level at the output.
Threshold – Adjust the input level at which compression will be active.
Gain – Use to compensate for the resulting attenuation of the signal.
In/Out – Enable or disable the compressor.
