162
Step Command Remarks
4. Configure the advertisable
TLVs (in Layer 3 Ethernet
interface view).
• lldp tlv-enable { basic-tlv { all |
port-description | system-capability |
system-description | system-name |
management-address-tlv [ ip-address ] }
| dot1-tlv { all | link-aggregation } |
dot3-tlv { all | mac-physic |
max-frame-size | power } | med-tlv { all
| capability | inventory |
power-over-ethernet | location-id
{ civic-address device-type country-code
{ ca-type ca-value }&<1-10> |
elin-address tel-number } } }
• lldp agent { nearest-nontpmr |
nearest-customer } tlv-enable { basic-tlv
{ all | port-description |
system-capability | system-description |
system-name | management-address-tlv
[ ip-address ] } | dot1-tlv { all |
link-aggregation } }
By default:
• Nearest bridge agents
can advertise all types
of LLDP TLVs (only link
aggregation TLV in
802.1
organizationally
specific TLVs) except
network policy TLVs.
• Nearest non-TPMR
bridge agents
advertise no TLVs.
• Nearest customer
bridge agents can
advertise basic TLVs
and IEEE 802.1
organizationally
specific TLVs (only link
aggregation TLV).
5. Configure the advertisable
TLVs (in Layer 2 aggregate
interface view).
• lldp agent nearest-nontpmr tlv-enable
{ basic-tlv { all | management-address-tlv
[ ip-address ] | port-description |
system-capability | system-description |
system-name } | dot1-tlv { all | evb |
port-vlan-id } }
• lldp agent nearest-customer tlv-enable
{ basic-tlv { all | management-address-tlv
[ ip-address ] | port-description |
system-capability | system-description |
system-name } | dot1-tlv { all |
port-vlan-id } }
• lldp tlv-enable dot1-tlv { protocol-vlan-id
[ vlan-id ] | vlan-name [ vlan-id ] |
management-vid [ mvlan-id ] }
By default:
• Nearest non-TPMR
bridge agents can
advertise only EVB
TLVs.
• Nearest customer
bridge agents can
advertise basic TLVs
and IEEE 802.1
organizationally
specific TLVs (only port
and protocol VLAN ID
TLV, VLAN name TLV,
and management
VLAN ID TLV).
Nearest bridge agents
are not supported on
Layer 2 aggregate
interfaces.
Configuring the management address and its encoding format
LLDP encodes management addresses in numeric or string format in management address TLVs.
By default, management addresses are encoded in numeric format. If a neighbor encodes its
management address in character string format, you must configure the encoding format of the
management address as string on the connecting port to guarantee normal communication with the
neighbor.
To configure a management address to be advertised and its encoding format on a port:
