37
2.
Configure the DHCP server
# Enable DHCP.
[SwitchA] dhcp enable
# Create DHCP address pool 0, configure a static binding, DNS server and gateway in it.
[SwitchA] dhcp server ip-pool 0
[SwitchA-dhcp-pool-0] static-bind ip-address 10.1.1.5 25
[SwitchA-dhcp-pool-0] static-bind client-identifier
3030-3066-2e65-3234-392e-3830-3530-2d56-6c61-6e2d-696e-7465-7266-6163-6532
[SwitchA-dhcp-pool-0] dns-list 10.1.1.2
[SwitchA-dhcp-pool-0] gateway-list 10.1.1.126
[SwitchA-dhcp-pool-0] quit
# Create DHCP address pool 1, configure a static binding, DNS server and gateway in it.
[SwitchA] dhcp server ip-pool 1
[SwitchA-dhcp-pool-1] static-bind ip-address 10.1.1.6 25
[SwitchA-dhcp-pool-1] static-bind mac-address 000f-e249-8050
[SwitchA-dhcp-pool-1] dns-list 10.1.1.2
[SwitchA-dhcp-pool-1] gateway-list 10.1.1.126
3.
Verification
After the preceding configuration is complete, Switch B can obtain IP address 10.1.1.5 and other network
parameters, and Switch C can obtain IP address 10.1.1.6 and other network parameters from Switch A.
You can use the display dhcp server ip-in-use command on the DHCP server to view the IP addresses
assigned to the clients.
Dynamic IP address assignment configuration example
Network requirements
•
As shown in
, the DHCP server (Switch A) assigns IP addresses to clients in subnet
10.1.1.0/24, which is subnetted into 10.1.1.0/25 and 10.1.1.128/25.
•
The IP addresses of VLAN-interfaces 1 and 2 on Switch A are 10.1.1.1/25 and 10.1.1.129/25
respectively.
•
In address pool 10.1.1.0/25, configure the address lease duration as ten days and twelve hours,
domain name suffix aabbcc.com, DNS server address 10.1.1.2/25, gateway 10.1.1.126/25, and
WINS server 10.1.1.4/25.
•
In address pool 10.1.1.128/25, configure the address lease duration as five days, domain name
suffix aabbcc.com, DNS server address 10.1.1.2/25, and gateway address 10.1.1.254/25, and
there is no WINS server address.
•
The domain name and DNS server address on subnets 10.1.1.0/25 and 10.1.1.128/25 are the same.
Therefore, the domain name suffix and DNS server address can be configured only for subnet
10.1.1.0/24. Subnet 10.1.1.128/25 can inherit the configuration of subnet 10.1.1.0/24.
NOTE:
In this example, H3C recommends that the number of DHCP clients that apply for IP addresses through
VLAN-interface 1 should be no more than 122, and that through VLAN-interface 2 should be no more
than 124.
