44
Hard drive status
The right part of the OSD shows the status of the hard drive where video data is recorded.
To turn HDD Overwrite ON/OFF, select {Main Setup} -> {Storage Device}.
ƒ When HDD Overwrite is turned ON ƒ When HDD Overwrite is turned OFF
Set the event recording frame and general recording frame separately
for automatic recording based on the setting.
When motion, sensor, or sound is detected, the event recording frame
is selected. Otherwise, the general recording frame is selected.
Recording is done based on the general frame setting.
Recording is done based on the event frame setting in case motion is
detected.
Recording is done based on the event frame setting in case of input
signal from an external sensor.
Recording is done based on the event frame setting in case sound is
detected.
Network access
The right part of the OSD shows the network connection status.
ƒ Network connected ƒ Network disconnected
4-7-4. Starting and Stopping Record All
To start or stop Record All, press the [Record] button on the remote control or on the [Record]
menu in real-time monitoring mode.
Overwrite
Overwrite Overwrite
