Section 8 Request 8-41
Request software will create a subdirectory here for each request and place
all the relevant files for the print job in that unique directory.
The Statusdir should match the drive and directory set on the controller in
the Unattend, Configuration, Miscellaneous, Log Directory. The Request
software will look to this directory for the updated paper and error information
created by the Unattend software at the Controller. The Log directory is
read each time the KIP Icon/title bar on the Request menu is selected with
the mouse.
The Machinetype allows the user to set a name for their printer. It does not
have to match the actual printer they own. For instance the user could give
the printer a personal name like “BOB”. This would be displayed on the KIP
icon/title bar.
Additional KIP Printers.
Users may create additional groups of printers to select from directly
underneath the current paths. For example:
[MultiplePrinters]
RequestDir0=C:\Monpath1\Request
StatusDir0=C:\Monpath1\LogDir
MachineType0=6000
RequestDir1=F:\abc\Request
StatusDir1=F:\abc\LogDir
MachineType1=3000 UL
RequestDir2=\\40Server\8000\Request
StatusDir2=\\40Sever\8000\LogDir
MachineType2=8000
In the Request software users can change from one printer to the next by
selecting the KIP icon/title bar at the top of the Request interface. This will
switch from one printer to the next and update the roll information at the
bottom of the Request interface.
[KipPortPrinters]
PrinterName1=~KIP 3000
[ConvertTypes]
Type0=Group4 TIF R
Type1=Group4 CAL R
Type2=ZSoft PCX R
Type3=HPGL PLT V
Type4=KIP TLC R
Type5=Group4 GP4 R
Type6=Postscript PS V
Type7=Postscript EPS V
Type8=Adobe PDF V
Type9=JPEG JPG R
Type10=Unknown 0?? V
Type11=Intergraph CIT R
Type12=ASCII xxx A
