Guntermann & Drunck CATCenter X systems Operation - Manual (Page 82)

Guntermann & Drunck GmbH CATCenter Operating Manual
Page 82
The field "Show" can be used to limit the list that is displayed.
All Shows all targets available on the CATCenter.
Available Shows only those targets that can be added to a group.
By default, this is set to "Available".
If the display setting is changed to "ALL", the targets that can be added to a
group are displayed in white. Targets that already belong to a group are
displayed in light blue.
For the targets already assigned to a group, the group name is displayed in the
right-hand column.
Use the F3 key to add a target to the current group. To do so, use the cursor
or the UP ARROW and/or DOWN ARROW keys on your keyboard to move to
the desired target and then press the F3 key. This is indicated by a cross in
front of the respective target. Pressing the F3 key again cancels the selection.
The changes are saved by pressing the F2 key. The selected targets are
added to the current group. You are returned to the GROUP MEMBERS
submenu.
5.4.2 F4 Delete Group
By pressing the F4 key, you can remove a group from the CATCenter system
within the TARGET GROUP CONFIG submenu. All changes that have been
made are saved automatically.
To do so, use the
UP ARROW and/or DOWN ARROW keys on your keyboard
or the mouse to select the corresponding entry in the TARGET GROUP
CONFIG submenu and then press the
F4 key (delete). A confirmation dialogue
opens with the following text:
Press the
ENTER key to confirm the deletion. Use the ESC key to cancel it.
C o n f i r m
Do you really want to delete
Target Group
Accounting?
ESC: Cancel
Enter: OK
