Guntermann & Drunck GmbH CATCenter Operating Manual
Page 85
5.5.3.1 Automatic Settings
You can establish all video settings automatically. To do so, you must be
connected to a target.
To activate this function, press the
F3 key. While the settings are being
established automatically, the monitor turns black for approx. 3 seconds. After
the automatic settings have been established, the display reappears.
After the automatic video setting process, save the settings by pressing the
F2
key. In this case, the IVT submenu is closed and you return to the
CONFIGURATION menu.
5.5.3.2 Manual Settings
In case, that the automatic setting doesn´t meet your expectations, you can
adjust the video display manually. This manually adjusting of the video display
is described in the following chapters.
5.5.3.2.1 Establishing the Video Boost
Boost: 4
The following keys are available to you to modify the video boost:
Key  Subtracts 1 from the video boost value
Key  Adds 1 to the video boost value
Keys CTRL +  Subtracts 5 from the video boost value
Keys CTRL +  Adds 5 to the video boost value
Home Maximum video boost (Caution: Overdrive possible 
no picture visible on monitor)
End Minimum video boost
If you want to make other changes within the IVT submenu, use the
UP
ARROW and/or DOWN ARROW keys to move to another entry.
After establishing the video boost, confirm and save your selection by pressing
F2 or discard your changes by pressing ESC . In both cases, the IVT submenu
is closed and you return to the CONFIGURATION menu.
