3.3 Parts Names and Their Functions 3
bizhub 161f 3-5
B
e
for
e
M
a
k
in
g
Cop
ies
or
F
a
x
ing
Chap
ter
3
2 Original Glass Place your original on this glass to allow the machine to scan it. The
original is to be placed face down. (p. 3-33)
3 Front Cover Open when replacing the Toner Cartridge or Drum Cartridge, or
clearing a paper misfeed. (p. 8-5)
4 Bypass Tray Use for manual feeding of paper.
Holds up to 10 sheets of paper.
Special paper can be used. (p. 3-29)
5 Tray1 door If Legal-size paper is installed, open this door.
6 Copy Tray Holds copies fed out face down from the machine.
The Copy Tray can be adjusted to one of three angles. Adjust the Copy
Tray to the angle appropriate for its application. (p. 3-8)
7 Tray1 Holds up to 250 sheets of paper and easily adjusts to different paper
sizes.
Special paper can be used. (p. 3-23)
8 Control Panel Use to start a print cycle and make necessary settings. (p. 3-11)
9 Exposure Lamp This lamp irradiates the document when it is scanned. The time until the
exposure lamp goes off can be specified. For details on specifying the
setting, refer to
“Selecting the “MACHINE SETTING” menu” on
page 7-4 .
10 Original Scales Use to align the original. (p. 3-33)
11 Power Switch Use to turn the machine on and off. (p. 3-16)
12 External telephone jack
(TEL PORT) Used for connecting a line to a telephone.
13 Telephone line jack for
line 1 (LINE PORT 1) Used for connecting to a standard telephone line.
14 USB Port For details, refer to the User’s Guide for the printer controller.
15 Parallel Port For details, refer to the User’s Guide for the printer controller.
16 Fuser Cover Open when clearing the misfed paper.
No. Part Name Description
