3 3.4 Control Panel
3-12 bizhub 161f
B
e
for
e
M
a
k
in
g
Cop
ies
or
F
a
x
ing
Chap
ter
3
8 [Scan] key Press to enter Scan mode. The indicator lights up in green to indicate
that the machine is in Scan mode.
(Available only when the Scanner Unit SU-502 is installed.)
9 [Fax] key Press to enter Fax mode. The indicator lights up in green to indicate that
the machine is in Fax mode.
10 [Copy] key Press to enter Copy mode. The indicator lights up in green to indicate
that the machine is in Copy mode.
11 [Stop] key • Press to stop a print cycle.
• Press to stop a scanning sequence.
• Stops the fax transmission or reception.
• The indicator flashes in orange when the machine is paused or while
printing.
12 [Panel Reset] key Press to reset all print functions and settings to their defaults.
13 [123/ABC] key Press to switch the 10-Key Pad between typing in numbers and typing
in letters.
14 [Start] key • Press to start a scanning or print cycle.
• Starts a fax transmission.
• Press to specify the various settings.
• The indicator lights up in green when the machine can accept print
jobs.
15 [
▲
] [
▼
] key • Press to change the zoom ratio in the range between
×
0.25 and
×
4.00 in
×
0.01 increments.
• Press to scan through the various settings and information, in order.
• Press to specify the various settings.
16 [Zoom] key Press to select a zoom ratio from among those fixed ratios available as
standard.
17 [Paper] key Press to select the paper tray that contains the desired paper.
18 [ ] [ Ö ] key • Press to adjust the image density.
• Press to specify the various settings.
19 [Auto/Photo] key Press to change the image density mode.
20 [Sort] key Press to select the sort function.
21 [2in1] key Press to select the 2in1 function.
22 [Status] key Press to view the counters and transmission results. In addition, the list
of settings specified for each function and the reports can be printed.
(p. 3-37)
23 Memory TX lamp Lights up when the memory transmission function is selected.
24 Auto RX lamp Lights up when the automatic reception function is selected.
25 [Resolution] key Used to select the image quality (transmission resolution).
26 [Speaker] key Press to answer the call. Press again to hang up.
27 [Phone Book] key Used to display the information programmed for one-touch dialing,
group dialing and speed dialing.
28 [Redial/Pause] key • Redials the last number called.
• While dialing, used to generate a pause when transferring from an
internal to an external line or receiving information services.
No. Part Name Description
