3.3 Parts Names and Their Functions
3-6
bizhub 161f
B
e
for
e
M
a
k
in
g
Cop
ies
or
F
a
x
ing
Chap
ter
3
Automatic Document Feeder
2
1
3
4
No.
Part Name
Description
1
Document Feeder Tray
Load the originals to be scanned face up on this tray.
Up to 50 document sheets can be loaded at one time. (p. 3-32)
2
Document Feeder
Cover (Doc. Feed
Cover)
Open when clearing an original that has been misfed. (p. 8-20)
3
Document Guide Plate
Slide the guide plate to the size of the originals. (p. 3-32)
4
Document Exit Tray
Receives originals which have been scanned by the machine.
