3.9 Loading Originals 3
bizhub 161f 3-31
B
e
for
e
M
a
k
in
g
Cop
ies
or
F
a
x
ing
Chap
ter
3
3.9 Loading Originals
Two Ways of Loading the Original
The original may be loaded in the Automatic Document Feeder or placed directly
on the Original Glass. Choose the appropriate method according to the type of the
original.
Specific Types of Originals
L: Lengthwise
Loading Originals in the Automatic Document Feeder
The Automatic Document Feeder automatically feeds originals one page after
another so that the machine can scan the data on each page. After the machine
finishes scanning the data, the Automatic Document Feeder ejects the page into
the Exit Tray. To ensure the best possible performance of the Automatic Document
Feeder, use only originals of the specified type.
Precautions for Loading Paper Into the Automatic Document Feeder
The following types of originals are not suitable for use in the Automatic Document
Feeder, as a misfeed or damaged original could result. Place such types of originals
on the Original Glass.
G Typing paper, paraffin paper, and other thin paper
G Cards
G Originals larger than Legal L or smaller than Half Letter
G OHP transparencies, translucent paper
G Wrinkled, dog-eared, curled, or torn originals
G Clipped or stapled originals
G Coated originals such as carbon-backed paper
G Up to 19 Letter-size document pages can be scanned and stored in the memory
at one time. However, if the optional expansion memory is installed, up to 180
scanned pages can be stored.
Original Loading Original Type Original Size
Automatic
Document Feeder Sheet originals
Weight of originals: 9-1/4 lb to 34 lb A4 L, B5 L, A5 L, Legal L, Letter L, Half
Letter L
• Original width: 5-1/2 to 8-1/2
• Original length: 5-1/2 to 14
Original Glass Max. weight of sheet originals, books, or
three-dimensional objects: 4-1/2 lb Maximum: Legal
