Start-Up - Blower
MODEL
VOLTS
SUP HP
MARK
AMPS
HTZ
PH
S/N
EXH HP
Voltage, Hertz,
and Phase
Step 1 Check the Voltage
Before starting the unit, compare the supplied voltage, hertz, and phase with the unit and motor’s nameplate
information.
Step 2 Check the Blower Rotation
Open the blower access door and run the blower momentarily to determine the rotation. Arrows are placed on
the blower scroll to indicate the proper direction.
IMPORTANT!
If the blower is rotating in the wrong direction, the unit will move some air, but will not perform as
designed. Be sure to perform a visual inspection to guarantee the correct blower rotation.
SPECIAL EQUIPMENT REQUIRED
Below is a list of special tools that are required. A recommended model is shown, but equivalent
products may be used.
Description
Manufacturer-Model
Phone
Website
Voltage Meter
Fluke-23
1-800-44-FLUKE
www.fluke.com
Amperage Meter
Fluke-23
1-800-44-FLUKE
www.fluke.com
Thermometer
Fluke-50
1-800-44-FLUKE
www.fluke.com
U-Tube manometer
Dwyer-Slack Tube
1-219-897-8000
www.dwyer-inst.com
Tachometer
Monarch-Pocket Tach 100
1-800-999-3390
www.monarchinstruments.com
WARNING!
Disconnect and lock-out all power and gas before
performing any maintenance or service to the
unit. Failure to do so could result in serious injury
or death and damage to equipment.
Pre Start-Up Check
Rotate the fan wheel by hand and make sure no parts
are rubbing. Check the V-belt drive for proper
alignment and tension (a guide for proper belt tension
and alignment is provided in the belt maintenance
section). Check fasteners, set screws and locking
collars on the fan, bearings, drive, motor base and
accessories for tightness. Remove any shipping
fasteners from the blower vibration isolators.
NOTE!
To reverse the rotation on three phase units, disconnect and lock-out the power, then interchange any
two power leads.
NOTE!
To reverse the rotation on single phase units, disconnect and lock-out the power, then rewire the
motor per the manufacturer’s instructions.
Start-Up
WARNING!
Check the housing, blower, weatherhood, filter section and ductwork for foreign objects and debris
before the blower is run.
