55
Operation - 4:1 Modulation & 8:1 Staged User Interface
Indicating Lights
Three indicating lights are located across the top of the display to indicate the status of the furnace.
4:1 Electronic Modulation
Light
On
Off
L1
Call for Heat
No Call for Heat
L2
Supply Fan On
Supply Fan Off
L3
Freeze Protection Tripped
Freeze Protection Satisfied
8:1 Staged Control (Single Furnace Units)
Light
On
Blinking
L1
Call for Heat
n/a
L2
n/a
Furnace at High Fire
L3
Burner Locked Out
Freeze Protection Tripped
8:1 Staged Control (Multi Furnace Units)
Light
On
Blinking
L1
n/a
n/a
L2
n/a
Alarm
L3
Program Mode
Saving New Settings
Operation
