2. Panel Operation DD35 Production Switcher
2 – 109 Operating Instructions – Rev. 16 / 10.2001
2.17 USER PROGRAMMABLE KEYS (UPKs)
Dedicated pushbutton functions of the DD35 control panel can be configured for
different tasks in future software versions. For indication purposes the control panel
is delivered with additional pushbutton inlays:
D
Set 1: GPO / Enbl GPO / Shot Box 1 / Shot Box 2
D
Set 2: Add / DVE1 / DVE2
D
Set 3: Cut1 Coupl / Cut2 Coupl / Cut3 Coupl
Cut4 Coupl / Cut5 Coupl / Cut6 Coupl
Auto1 T-Dur / ... / Auto6 T- / 2
nd Fct
D
Set 4: DVE1 Video / DVE1 Key
DVE2 Video / DVE2 Key
D
Special pushbutton inlays for more user programmable keys
From Software Release V2.3.9 onwards, all Next Transition buttons (Bgd A, Bgd
B, Key 1,2,3) are UPKs.
That means that they can be assigned to any UPK function of the Transition panel,
and that the original functions of the buttons are now also available as UPK function
of the Transition panel. The purpose is to shift the button assignment for RPS35–4
panels which are not provided with the button Next–Trans–Key 3:
Old: Bgd B Bgd A Key 1 Key 2
New: Bgd A Key 1 Key 2 Key 3
This causes the problem that the Key 3 button operates in the Layered mode Bgd
A, but Bgd B is missing so that the following assignment would be obtained:
(Layered mode)
Old:
Bgd B Bgd A Key 1 Key 2
New: Bgd A Key 1 Key 2 Bgd A
For this reason, in the menu Install / Panel / UPK there is still a special UPK function
”Bgd A (Bgd B in layered mode)” available for the Layered mode, which normally
operates Bgd A, but in the Layered mode it operates Bgd B. With this function on
the first button, the following assignment is obtained:
(Non–layered mode)
New:
Bgd A Key 1 Key 2 Key 3
(Layered mode)
New:
Bgd B Key 1 Key 2 Bgd A
From Software Release V2.3.9 onwards addition UPK added: Next Transition
buttons, FTB–Cut, FTB–Auto, Transi–Loop, Transi BlackPreset
From Software Release V3.1.1 onwards addition UPK in the Aux panel section
added and Wait, Continue.
Refer to the menu Install / Panel / UPK (section 3.16.3) for details and a complete
list of all available UPKs.
