3. Menu Operation DD35 Production Switcher
3 – 202 Operating Instructions – Rev. 16 / 10.2001
Pulses on OUTPUT processor.
output / H1 pulse
output / H2 pulse
output / H3 pulse
output / H4 pulse
output / HIN pulse
output / HOUT pulse
output / HAUX pulse
output / HBGDST pulse
output / F pulse
output / AUXBL pulse
output / V pulse
output / CLK pulse
output / FC pulse
output / no genlock reference
If a local error message occurs, the alarm output conducts at the rear of the main-
frame.
Additionally a yellow warning triangle is displayed in all menus. Mouse
click on this warning sign opens the diagnosis menu also.
Note: The displayed characters “ X___ ” symbolizes the position of the
power supply unit in the rack.
