5. Application Notes DD35 Production Switcher
5 – 7 Operating Instructions – Rev. 16 / 10.2001
Input1 and Input2 exist as SD source and as HD source. It is applied at the respec-
tive Input1 of the corresponding switcher.
Input2 and Input3 only exist for the SD. The corresponding input connectors in the
HD are not assigned. When selecting Input3, the LAN Input Substitution switches
in the HD to Input 2.
Input5 and Input6 only exist for the HD. The corresponding input sockets in the
SD are not assigned. When selecting Input5, the LAN Input Substitution switches
in the SD to Input4.
