3. Menu Operation
DD35 Production Switcher
3 – 259
Operating Instructions – Rev. 16 / 10.2001
The list box displays all device resources available for an application at the DD35
network.
Such resources are:
D
All mainframes
D
All stand alone sidepanels
D
All stand alone control panels
D
All control units (SP + attached CP)
Control units should be represented as two devices, marked as one unit. Entries
belonging to the own application are marked with a green background. The color
background at the cursor position is blue.
The enter conditions of the edit devices menu ensures, that a mainframe is allways
allocated to an application. Thus the connected mainframe is always marked with
the green background. If the name of a device is not available, the IP-address is
displayed instead.
3.17.5.1 Dialog Buttons
Selecting Config menu.
Selecting Config E-Box menu.
Selecting Config Panel menu.
Selecting Allocate Resources menu.
Return to the previous menu. For details refer to section Introduction.
Device list box
Config
E-Box
Panel
Allocate Resources
Previous Menu
