Output Instance Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
166
11
22 <1>
Parameter F7-34
Default: Output Power (Low Byte)
23 <1>
Parameter F7-34
Default: Output Power (High Byte)
12
24 <1>
Parameter F7-35
Default: Terminal A2 Input (Low Byte)
25 <1>
Parameter F7-35
Default: Terminal A2 Input (High Byte)
13
26 <1>
Parameter F7-36
Default: Terminal S1 to S8 Input (Low Byte)
27 <1>
Parameter F7-36
Default: Terminal S1 to S8 Input (High Byte)
14
28 <1>
Parameter F7-37
Default: Terminal A3 Input (Low Byte)
29 <1>
Parameter F7-37
Default: Terminal A3 Input (High Byte)
15
30 <1>
Parameter F7-38
Default: PG Counter (Ch2) (Low Byte)
31 <1>
Parameter F7-38
Default: PG Counter (Ch2) (High Byte)
16
32 <1>
Parameter F7-39
Default: NetRef and NetCtrl (Low Byte)
– – – – – – NetCtrl NetRef
33 <1>
Parameter F7-39
Default: NetRef and NetCtrl
17
34 <1>
Parameter F7-40
Default: Drive Software Version (Low Byte)
35 <1>
Parameter F7-40
Default: Drive Software Version (High Byte)
18
36 <1>
Parameter F7-41
Default: Not Used
37 <1>
Parameter F7-33
Default: Not Used
19
38 <1>
Parameter F7-33
Default: Not Used
39 <1>
Parameter F7-42
Default: Not Used
20
40 – – – – – –
Assy. 116
F7-32
Error
Assy. 116
F7-31
Error
41
Assy. 116
F7-30
Error
Assy. 116
F7-29
Error
Assy. 116
F7-28
Error
Assy. 116
F7-27
Error
Assy. 116
F7-26
Error
Assy. 116
F7-25
Error
Assy. 116
F7-24
Error
Assy. 116
F7-23
Error
21 42 – – – – – –
Assy. 166
F7-42
Error
Assy. 166
F7-41
Error
43
Assy. 166
F7-40
Error
Assy. 166
F7-39
Error
Assy. 166
F7-38
Error
Assy. 166
F7-37
Error
Assy. 166
F7-36
Error
Assy. 166
F7-35
Error
Assy. 166
F7-34
Error
Assy. 166
F7-33
Error
<1> Selectable with F7-33 to F7-42.
Name Description
Running
Running
0: Stop
1: Forward or Reverse Running
Zero Speed
Zero Speed
0: Running
1: Stop or DC Injection Braking
REV Running
Reverse Running
0: Not Reverse Running
1: Reverse Running
9 Input Assemblies (Drive Produces)
