Ethernet link object 246 (class 0xf6), Services supported, Attributes supported – Yaskawa SI-EN3D User Manual
Page 48
Instance
ID
Attribute
Name
Description
Get
Set
Size
Range
Default
1
2
Configuration
Capability
Bit 0 = BOOTP Client
Bit 1 = DNS Client
Bit 2 = DHCP Client
Bit 3 = DHCP-DNS Update
Bit 4 = Configuration Settable
Bits 5-31 = Reserved
O
–
DWord
–
–
1
3
Configuration
Control
Bits 0-3 = Startup Configuration
0: NVRAM
1: BOOTP
2: DHCP
3: Reserved
Bit 4 =DNS Enabled (not supported)
Bits 5-31 = Reserved
O
O
DWord
–
–
1
4
Physical Link
Struct of:
Path Size: 0
Path: 0
O
–
Struct
–
02H 00H 20H
F6H 24H 01H
1
5
Interface
Configuration
Struct of:
IP Address = Long
Subnet Mask = Long
Gateway Address = Long
Name Server1 = Long
Name Server2 = Long
Domain Name = STRING
O
O
Struct
–
–
1
6
Host Name
Host Name
O
O
STRING
64 char
Null
1
10
Select ACD
Activates use of ACD
0: Disable ACD
1: Enable ACD
O
O
BOOL
0, 1
1
1
11
Last Conflict
Detected
Structure containing information
related to the last conflict detected.
Struct of:
Bit 0: ACD Activity
Bits 1-7: Remote MAC
Bits 8-36: ARP PDU
O
O
Struct
–
–
Note:
“Get Attributes All” Service shall report in attribute ascending order.
u
Ethernet Link Object 246 (Class 0xF6)
n
Services Supported
Service Code No. (Hex)
Service Name
01
Get Attribute All
0E
Get Attribute Single
10
Set Attribute Single
n
Attributes Supported
Instance
ID
Attribute
Name
Description
Get
Set
Size
Range
Default
0
1
Object Software
Revision
Revision number of the TCP/IP Object
O
–
Word
–
3
0
2
Max Instance
–
O
–
UINT
–
2
0
3
Number of
Instances
–
O
–
UINT
–
2
1
1
Interface Speed Interface speed currently in use
O
–
UDINT
–
–
10 General Class Objects
48
