Instance
ID
Attribute Name Description Get Set Size Range Default
1 2 Interface Flags
Bit 0 = Link Status
Bit 1 = Duplex (0: Half/1: Full)
Bits 2-4 = Negotiation Status
0: In progress
1: Auto-negotiate failed
2: Speed found, duplex not found
3: Successful
4: Not attempted
Bit 5 = Manual Setting requires restart
Bit 6 = Local hardware fault
Bits 7-31 = Reserved
O – DWord – –
1 3
Physical
Address (MAC) MAC address
O –
Array of 6
Bytes
– –
1 6
Interface
Control
Struct of:
Control Bits: Word
Bit 0 = Auto-negotiate
Bit 1 = Forced Duplex Mode
Bits 2-15 = Reserved
Forced Int Speed: Word
– O Struct – –
1 10 Interface Label – O – Short String – Port 1
2 1 Interface Speed Interface speed currently in use O – UDINT – –
2 2 Interface Flags
Bit 0 = Link Status
Bit 1 = Duplex (0: Half/1: Full)
Bits 2-4 = Negotiation Status
0: In progress
1: Auto-negotiate failed
2: Speed found, duplex not found
3: Successful
4: Not attempted
Bit 5 = Manual Setting requires restart
Bit 6 = Local hardware fault
Bits 7-31 = Reserved
O – DWord – –
2 6
Interface
Control
Struct of:
Control Bits: Word
Bit 0 = Auto-negotiate
Bit 1 = Forced Duplex Mode
Bits 2-15 = Reserved
Forced Int Speed: Word
– O Struct – –
2 10 Interface Label – O – Short String – Port 2
Note: “Get Attributes All” Service shall report in attribute ascending order.
10 General Class Objects
