User interface
Page 40 Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN
Country-
specific
Menu
level
Display/
Setting
Menu
type
Action in the menu/Meaning
All
countries
0 1 2 3 4
User Configu-
ration
Configuring user settings.
4 0 1 2 3
Email Server
Configuring the e-mail server (see section 9.4 on
page 70).
0 1 2 3 4
Network
Setting the network parameters (see section 8.4.8.5 on
page 48).
0 1 2 3 4
Service Selecting the service parameter groups.
4 0 1 2 3
Grid Setting the grid parameters.
4 0 1 2 3
Inverter Setting the inverter parameters.
4 0 1 2 3
PV array Setting the PV generator parameters.
4 0 1 2 3
Controller Operating the system in test mode.
0 1 2 3 4
Software
Upgrade
Performing a software upgrade from SD card
(see section 8.4.8.6 on page 49).
4 0 1 2 3
MMI Updating the MMI software.
4 0 1 2 3
C6x Updating the C6x software.
0 1 2 3 4
Information
Displays the following information:
• Type designation of the inverter
• Installed software version
• Selected country setting
• Grid type, if selected
0 1 2 3 4
PV Array
Displays measured values of the PV generator (see sec-
tion 8.4.1 on page 42).
Activating the string monitoring.
0 1 2 3 4
Strings
Displays the current values recorded by string monitoring
(see section 8.4.2 on page 43).
0 1 2 3 4
Inverter
Displays measured values of the inverter (see section 8.4.3
on page 43).
0 1 2 3 4
Grid
Displays measured values of the power grid (see sec-
tion 8.4.4 on page 43).
0 1 2 3 4
Start Inverter Starting the inverter.
0 1 2 3 4
Stop Inverter Stopping the inverter.
0 1 2 3 4
Stop speaker
Switching on/off the speaker (see section 8.3.2 on
page 42).
0 1 2 3 4
SD card safe-
remove
Displays the SD card status (see section 8.3.1 on page 41).
Acknowledging the “SD card in slot” status.
