User interface
Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN
Page 47
8.4.8.1 Date/Time
NOTE
Set the current date and local time. This setting affects the logging functions (event log and statis-
tics).
1
2
Date/Time
Year
Month
Day
Hour
Minute
2010
6
4
14
52
Set
Set
Set
Set
Set
back
Figure 53: “Date/Time” screen
Changing system time
"
This is where you set the current date and local time.
After the values have been changed, it takes up to one minute for the time data that is displayed in the main menu
to be updated.
8.4.8.2 Recording
Specifying which values will be recorded
"
Set the recording interval (in minutes).
"
On pages 1 and 2 specify which values are to be
recorded.
1
2
Recording
Interval (min)
Grid power
PV power
PV voltage
PV current
10
ON
ON
ON
ON
Set
Set
Set
Set
Set
back
Figure 54: “Recording” screen
You can use this menu item to delete all of the statis-
tics data on the SD card (if necessary).
8.4.8.3 Recording settings
ID Name
Unit
Factory setting
Min.
Max.
0
Recording interval
minute
10
10
60
1
Grid power
ON
OFF
ON
2
PV power
ON
OFF
ON
3
PV voltage
ON
OFF
ON
4
PV current
ON
OFF
ON
5
PV temperature
OFF
OFF
ON
6
Insolation
OFF
OFF
ON
7
Statistics
Clear
-
-
Table 16: Recording settings
