KACO Powador XP200-HV TL - Manual (Page 74)

Configuration
Page 74 Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN
User Configuration
Buzzer on Faults
Buzzer on Warnings
Service Mode
RTU Enable
RTU ID
ON
ON
OFF
OFF
–1
Set
Set
Set
Set
Set
back
1
2
User Configuration
RTU Report Hour
RTU Report Minute
Get RTU Profile
Email Server
0
0
N/A
N/A
Set
Set
Set
Set
Set
back
1
2
3. On the “User Configuration“ screen press the down arrow to select the second page.
4. Press the “Set“ button for “Email Server“.
Powador Web
Individual Server 1
Individual Server 2
Individual Server 3
Email Server Individual Server
SMTP IP Address
Enable Interval 
SMTP Username
SMTP Password
Plant Name
3
Set
Set
Set
Set
Save
1 2
5. On the “Email Server“ screen press one of the “Individual Server X” buttons.
6. On the “Individual Server” screen press the “Enable“ check box.
7. Press the “Interval” drop-down combo box and select the transmission interval (example: 5).
Individual Server
SMTP IP Address
Enable Interval 
SMTP Username
SMTP Password
Plant Name
5
Set
Set
Set
Set
Save
Individual Server
SMTP IP Address
[email protected]
mmi123
LONDON
Enable Interval 
SMTP Username
SMTP Password
Plant Name
5
Set
Set
Set
Set
Save
mail.kaco-newenergy.kr
2
1
8. On the “Individual Server” screen change the following parameters (see section 8.4.8 on page 46):
– For “SMTP IP Address” input the address of the e-mail server.
– For “SMTP Username“ input the SMTP username .
– For “SMTP Password“ input the password for the SMTP user.
– If you want to set a name for the inverter: For “Plant Name“ input the name for the inverter.
9. Check if the parameters were changed to the set values.
10. Press the switching button to open the next page of the “Individual Server” screen.
