Kyocera Taskalfa 3511i - Manual (Page 499)

10-18
Troubleshooting > Troubleshooting
Cannot print with USB
memory.
USB memory not
recognized. Is the USB host blocked? Select [Unblock] in the USB host
settings. page 8-63
― Check that the USB memory is
securely plugged into the machine. ―
While "Auto-IP" is already
set to [On], the IP
address is not assigned
automatically. Is a value other than "0.0.0.0"
entered for the link local address of
TCP/IP(v4)? Enter "0.0.0.0" for the IP address of
TCP/IP(v4). page 2-30
Cannot send via SMB. Is the network cable connected? Connect the correct network cable
securely. page 2-7
Have the network settings for the
equipment been configured
properly? Configure the TCP/IP settings
properly. page 8-47
Have the folder sharing settings
been configured properly? Check sharing settings and access
privileges under the folder
properties. page 3-14
Is the selected interface selected as
the Primary Network? Specify the host name or IP address
of the interface selected as the
Primary Network, or set the
interface to be used again. page 8-62
Has the SMB protocol been set to
[On]? Set the SMB protocol setting to
[On]. page 8-54
Has [Host Name] been entered
properly?
*1
Check the name of the computer to
which data is being sent. page 5-23
Has [Path] been entered properly? Check the share name for the
shared folder. page 5-23
Has [Login User Name] been
entered properly?
*1 *2
Check the domain name and login
user name. page 5-23
Has the same domain name been
used for [Host Name] and [Login
User Name]? Delete the domain name and
backslash ("/") from [Login User
Name]. page 5-23
Has [Login Password] been
entered properly? Check the login password. page 5-23
Have exceptions for Windows
Firewall been configured properly? Configure exceptions for Windows
Firewall properly. page 3-17
Do the time settings for the
equipment, domain server, and data
destination computer differ? Set the equipment, domain server,
and data destination computer to
the same time. ―
Is the screen displaying Send error? Refer to Responding to Send Error . page 10-35
Cannot connect to this
machine by using Wi-Fi
Direct. Are three handheld devices
connected simultaneously? Release the connection of handheld
devices being connected manually
or set a connection after setting the
connection time and releasing the
connection by automatic
disconnection. page 8-49
Symptom Checkpoints Corrective Actions
Reference
Page
