Dell OptiPlex 7010 Small Form Factor Desktop Computer - Manual (Page 23)

Table 10. Wireless module specifications (continued)
Description Option one Option two Option three
Encryption
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
● 64-bit/128-bit WEP
● AES-CCMP
● TKIP
Bluetooth wireless card
Bluetooth wireless card Bluetooth wireless card Bluetooth wireless card
NOTE: The version of the Bluetooth wireless card may vary depending on the operating
system that is installed on your computer.
Audio
The following table lists the audio specifications of your OptiPlex Small Form Factor 7010.
Table 11. Audio specifications
Description Values
Audio controller
Realtek ALC3246-CG
Stereo conversion
Supported
Internal audio interface
High definition audio
External audio interface
Universal Audio Jack port, Audio Line-out
Number of speakers
One
Internal-speaker amplifier Codec built-in amp
External volume controls
Not supported
Speaker output:
Average speaker output 2 W
Peak speaker output
2.5 W
Subwoofer output
Not supported
Microphone
Internal Mic not available
Storage
This section lists the storage options on your OptiPlex Small Form Factor 7010.
Table 12. Storage matrix
Storage 2.5-inch
hard-disk
drive
3.5-inch
hard-disk
drive
M.2
2230/2280
socket
M.2 via PCIe
card
M.2 solid-state drive No No Yes No
M.2 solid-state drive + 2.5-inch hard-disk drive Yes No Yes No
M.2 solid-state drive + 3.5-inch hard-disk drive No Yes Yes No
Specifications of OptiPlex Small Form Factor 7010 23
