Expansion card
Removing the graphics card
Prerequisites
1. Follow the procedure in Before working inside your computer .
2. Remove the side cover .
3. Remove the front bezel .
4. Remove the 2.5-inch hard drive if applicable.
5. Remove the 3.5-inch hard drive if applicable.
6. Remove the disk-drive cage .
About this task
The following image indicates the location of the graphics card and provides a visual representation of the removal procedure.
Steps
1. Pull to open the PCIe latch that secures the graphics card.
64 Removing and installing Customer Replaceable Units (CRUs)
