User interface
Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN Page 53
8.5.3 Grid parameters
Parameter Unit Range Description Factory settings
Rated Grid Voltage V 208 ... 400 Rated value of the grid voltage Device-specific
Rated Grid
Frequency
Hz 50 ... 60 Rated value of the grid frequency 60
Grid Over Voltage
Level 1
% 105 ... 125 Upper limit expressed as a percen-
tage of the rated grid voltage for grid
overvoltage level 1
110
Grid Under Voltage
Level 1
% 75 ... 110 Lower limit expressed as a percen-
tage of the rated grid voltage for grid
under voltage Level 1
90
Grid Over Fre-
quency Level 1
Hz 0.0 ... 3.0 Upper limit for grid over frequency
level 1
0.2
Grid Under
Frequency Level 1
Hz 0.0 ... 3.0 Lower limit for grid under frequency
level 1
2
Frequency
Dependant Power
Reduction Enable
– On(1), Off(0) “On” means that the frequency-
dependant power reduction is wor-
king
0
Power Gradient
Enable
– On(1), Off(0) “On” means tat the power gradient is
working
1
Power Gradient
Ramp
s 0.0 ... 600 Time for power gradient ramp
The inverter must generate the active
power slowly with specific slope
when its operation stops. In this case,
the active power supply cannot be
>10 % of the rated active power per
minute.
600
Time shift s 0.0 ... 6000 Delay time for inverter start 0
Gate-way Enable – 0.0 ... 1.0 Reserved parameter 0
Grid Level 2
Protection Enable
– On(1), Off(0) “On” means that grid level 2 protec-
tion is working
1
Grid Over Voltage
Level 2
% 105 ... 130 Upper limit expressed as a percen-
tage of the rated grid voltage for grid
overvoltage level 2
120
Grid Under Voltage
Level 2
% 75 ... 100 Lower limit expressed as a percen-
tage of the rated grid voltage for grid
under voltage Level 2
80
Grid Under
Frequency Level 2
Hz 0.0 ... 3.0 Lower limit for grid under frequency
level 2
2.5
Grid Over Voltage
Level 1 Trip time
ms 1000 ... 10000 Time for grid over voltage level 1 trip 5000
Grid Over Voltage
Level 2 Trip time
ms 40 ... 2000 Time for grid over voltage level 2 trip 100
Grid Under Voltage
Level 1 Trip time
ms 1000 ... 10000 Time for grid under voltage level 1
trip
5000
