Faults and Warnings
Page 84 Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN
Message Code Description
Cabinet Under Temp. Warning W51 The temperature in the cabinet is below the parameter [Cabi-
net temperature minimum].
SP3 (Control Power SP) Failure W52 Failure of surge (overvoltage) protector SP3 for the control
power
CB32 Open W53 Circuit breaker CB32 has tripped
SMPS warning W54 Failure of SMPS (Switched-mode power supply)
CAN Wrong Message W59 Received CAN message is wrong formatted
CAN Time Out W60 No CAN message has been received in the last 2 seconds.
CAN Multiple Master W61 Multiple inverters are working as a master in the CAN net-
work.
Table 31: Warnings
12.2 Errors
Message Code Description
PV Over Voltage F01 PV voltage > parameter [DC over voltage level]
PV Over Current F02 PV current > parameter [DC over current level]
CB10 (PV CB)Trip F04 Failure of circuit breaker CB10 on the PV side
PV Polarity Reversal F05 The polarity (+, -) of the PV side is reversed.
Ground Fault F06 Ground Fault has been detected
Inverter Over Voltage F10 Overvoltage on the inverter side
Inv. Under Voltage F11 Undervoltage on the inverter side
Inv. Over Frequency F12 Overfrequency on the inverter side
Inv. Under Frequency F13 Underfrequency on the inverter side
Inv. Over Current F14 Overcurrent on the inverter side
Inv. MC (MC21) Failure F15 Magnet contact failure on the inverter side
Inv. Phase Order Failure F16 Phase order is wrong
Inductor or TR Over Temp. F18 Temperature of chokes > 150°C
Inv. Current Unbalance F19 Phase unbalance > 20%
PEBB(1) IGBT Failure F20 The PEBB for IGBT 1 has failed
PEBB(2) IGBT Failure F21 The PEBB for IGBT 2 has failed
PEBB(3) IGBT Failure F22 The PEBB for IGBt 3 has failed
PEBB Over Temp. Analog F24 Heatsink temperature > 85°C
PEBB Over Temp. Digital F25 The thermostat switch tripped due to heatsink overtemperature.
Grid Over Voltage F30 Overvoltage on the grid side
Grid Under Voltage F31 Undervoltage on the grid side
Table 32: Fault
