User interface
Operating Instructions Powador XP200-HV TL, XP250-HV TL, XP350-HV TL_EN Page 57
Parameter Unit Range Description Factory settings
Unbalanced Current
Limit
% 0 ... 100 Unbalanced current level 20
Cabinet FAN PWM – 0 ... 100 Reserved parameter 100
Remote Power Con-
trol Ramp
s 0 ... 600 Slope of inverter output active poser
when remote power is controlled
10
Total Yield kWh 0 ... 99999999 Total yield of generation (read only) –
Today Yield kWh 0 ... 99999999 Day yield of generation (read only) –
IIVCD P Gain – 0 ... 99999 P gain of inverter output voltage
controller D-axis for initial operation
voltage
0.2
IIVCQ I Gain – 0 ... 99999 I gain of inverter output voltage
controller Q-axis for initial operation
voltage
5
Anti-Islanding
Enable
– 0 ... 99999 Usage of anti-islanding controller
• 0: no
• 1: yes
If the anti-islanding function is acti-
vated and a grid failure occurs, the
inverter automatically disconnects
itself from the power grid within a
few seconds.
If the anti-islanding function is not
activated, the inverter generates
power to load during grid failure.
0
APS Line Deadband – 0 ... 99999 Setup value for anti-islanding control 0.11
Reactive Power
Limit
– 0 ... 99999 Setup value for anti-islanding control 0.06
Wind Speed – 0 ... 99999 Reserved parameter –
Power Derating
Enable
– 0 ... 1 Usage of power decline controller
according to PEBB temperature
• 0: no
• 1: yes
0
Power Derating
Enable Temperature
– 50 ... 100 Temperature level which starts
decreasing power according to PEBB
temperature
70
Power Derating
Disable Tempera-
ture
– 40 ... 90 Temperature level which stops
decreasing power according to PEBB
temperature
50
Power Derating
Reference Tempe-
rature
– 45 ... 95 PEBB temperature reference value 60
Power Derating P
Gain
– 0 ... 10 P gain of power declining controller
according to PEBB temperature
2
Grid IIR Filter Cutoff
Frequency
Hz 0 ... 10 Filter cut-off frequency used for RMS
value detection of grid voltage
1.5
