Roland OCTA-CAPTURE - High-Speed USB Audio Interface - Manual (Page 33)

33
Controlling the Preamp
CHANNEL [ ], [ ] Buttons
Select the channel (1–8) that you want to control.
The currently selected channel is shown in the LCD.
[SENS] knob
Set the preamp gain of the currently selected input channel.
When you turn the [SENS] knob, the amount of gain is shown in the LCD.
Signal Status Indicator
SIG indicator
Clip indicator
This shows the status of the signals being input to the OCTA-CAPTURE.
SIG indicator This will light when a signal is input.
Clip indicator
This will light when the input signal reaches -2 dB.
The CHANNEL [ ] [ ] buttons will also blink in
tandem with the clip indicator.
