Pressure gauge test – Fluke Biomedical BP Pump 2 User Manual
Page 48
BP Pump 2
Operators Manual
3-12
Press
u
re So
u
rce
GAUGE
SETUP
V
E
N
T
<START>
Meas
u
red : 0.4
Setpoint : 200
mm Hg
mm Hg
fas05.eps
4. Press the
VENT
soft key to release any unwanted pressure in the system
before performing the test. This feature vents the system for approximately
five seconds and can be repeated as needed to return pressure to zero.
5. Press the
<START>
soft key to make the Tester deliver air to the system. The
Tester pressurizes the system within 10 mmHg of the Setpoint value.
Note
Once the Setpoint has been reached, the Tester will not maintain the
pressure in the system. Therefore, it is recommended that the system be
checked for leaks prior to performing any static pressure tests.
6. Press
HOME
to return to the
Main
menu.
Pressure Gauge Test
The Pressure Gauge Test enables the Tester to measure static pressure generated
by an external source in the range of 0 to 400 mmHg (0 to 53.3 kPa).
To measure static pressure, take the following actions:
1. Use the soft keys to follow the menu path shown below.
PRESSURE TESTS
C
STATIC PRESSURE
The
Pressure Gauge
screen appears.
Press
u
re G
u
age
SOURCE
V
E
N
T
Meas
u
red: 0
0.4 mm Hg
fas06.eps
2. Press the
VENT
soft key to release any unwanted pressure in the system
before performing the test. This feature vents the system for approximately
five seconds and can be repeated as needed to return pressure to zero.
