Preassembly
Foil
Length
Instruction
April 2000
Unit 3.25 MKIII
14
WARNING
If you make any cuts in the foils be sure to carefully clean all shavings from inside the foils. Failure to deburr or
clean the inside of the foils may cause them to seize to the connector during installation.
■
You will use a recessed top connector (page 16).
■
Do not cut 24" (610 mm) bottom foil.
55'4" (16.866 m)
62'4" (18.999 m )
69'4" (21.133 m)
76'4" (23.266 m)
83'4" (25.400 m)
1'7" (483 mm)
55'6" (16.916 m)
62'6" (19.050 m)
69'6" (21.184 m)
76'6" (23.317 m)
83'6" (25.450 m)
1'9" (533 mm)
55'8" (16.967 m)
62'8" (19.101 m)
69'8" (21.234 m)
76'8" (23.368 m)
83'8" (25.502 m)
1'11" (584 mm)
55'10" (17.018 m)
62'10" (19.152 m)
69'10" (21.285 m)
76'10" (23.419 m)
83'10" (25.552 m)
2'1" (635 mm)
56'0" (17.069 m)
63'0" (19.202 m)
70'0" (21.336 m)
77'0" (23.470 m)
84'0" (25.603 m)
2'3" (686 mm)
56'2" (17.120 m)
63'2" (19.253 m)
70'2" (21.387 m)
77'2" (23.520 m)
84'2" (25.654 m)
2'5" (737 mm)
56'4" (17.170 m)
63'4" (19.304 m)
70'4" (21.438 m)
77'4" (23.571 m)
84'4" (25.705 m)
2'7" (787 mm)
56'6" (17.221 m)
63'6" (19.355 m)
70'6" (21.488 m)
77'6" (23.622 m)
84'6" (25.756 m)
2'9" (838 mm)
56'8" (17.272 m)
63'8" (19.406 m)
70'8" (21.539 m)
77'8" (23.673 m)
84'8" (25.806 m)
2'11" (889 mm)
56'10" (17.323 m)
63'10" (19.456 m)
70'10" (21.590 m)
77'10" (23.724 m)
84'10" (25.857 m)
3'1" (940 mm)
57'0" (17.374 m)
64'0" (19.507 m)
71'0" (21.641 m)
78'0" (23.774 m)
85'0" (25.908 m)
3'3" (991 mm)
57'2" (17.424 m)
64'2" (19.558 m)
71'2" (21.692 m)
78'2" (23.825 m)
85'2" (25.959 m)
3'5" (1.041 m)
57'4" (17.475 m)
64'4" (19.609 m)
71'4" (21.742 m)
78'4" (23.876 m)
85'4" (26.010 m)
3'7" (1.092 m)
57'6" (17.526 m)
64'6" (19.659 m)
71'6" (21.793 m)
78'6" (23.927 m)
85'6" (26.060 m)
3'9" (1.143 m)
57'8" (17.577 m)
64'8" (19.710 m)
71'8" (21.844 m)
78'8" (23.978 m)
85'8" (26.111 m)
3'11" (1.194 m)
57'10" (17.628 m)
64'10" (19.761 m)
71'10" (21.895 m)
78'10" (24.028 m)
85'10" (26.162 m)
4'1" (1.245 m)
58'0" (17.679 m)
65'0" (19.812 m)
72'0" (21.946 m)
79'0" (24.079 m)
86'0" (26.213 m)
4'3" (1.295 m)
58'2" (17.729 m)
65'2" (19.863 m)
72'2" (21.996 m)
79'2" (24.130 m)
86'2" (26.264 m)
4'5" (1.346 m)
58'4" (17.780 m)
65'4" (19.914 m)
72'4" (22.047 m)
79'4" (24.181 m)
86'4" (26.314 m)
4'7" (1.397 m)
58'6" (17.831 m)
65'6" (19.964 m)
72'6" (22.098 m)
79'6" (24.231 m)
86'6" (26.365 m)
4'9" (1.448 m)
58'8" (17.882 m)
65'8" (20.015 m)
72'8" (22.149 m)
79'8" (24.282 m)
86'8" (26.416 m)
4'11" (1.499 m)
58'10" (17.932 m)
65'10" (20.066 m)
72'10" (22.200 m)
79'10" (24.333 m)
86'10" (26.467 m)
5'1" (1.549 m)
59'0" (17.983 m)
66'0" (20.117 m)
73'0" (22.250 m)
80'0" (24.384 m)
87'0" (26.518 m)
5'3" (1.600 m)
59'2" (18.034 m)
66'2" (20.168 m)
73'2" (22.301 m)
80'2" (24.435 m)
87'2" (26.568 m)
5'5" (1.651 m)
59'4" (18.085 m)
66'4" (20.218 m)
73'4" (22.352 m)
80'4" (24.486 m)
87'4" (26.619 m)
5'7" (1.702 m)
59'6" (18.136 m)
66'6" (20.269 m)
73'6" (22.403 m)
80'6" (24.536 m)
87'6" (26.670 m)
5'9" (1.753 m)
59'8" (18.186 m)
66'8" (20.320 m)
73'8" (22.454 m)
80'8" (24.587 m)
87'8" (26.721 m)
5'11" (1.803 m)
59'10" (18.237 m)
66'10" (20.371 m)
73'10" (22.504 m)
80'10" (24.638 m)
87'10" (26.772 m)
6'1" (1.854 m)
60'0" (18.288 m)
67'0" (20.422 m)
74'0" (22.555 m)
81'0" (24.689 m)
88'0" (26.822 m)
6'3" (1.905 m)
60'2" (18.339 m)
67'2" (20.472 m)
74'2" (22.606 m)
81'2" (24.740 m)
88'2" (26.873 m)
6'5" (1.956 m)
60'4" (18.390 m)
67'4" (20.523 m)
74'4" (22.657 m)
81'4" (24.790 m)
88'4" (26.924 m)
6'7" (2.007 m)
60'6" (18.440 m)
67'6" (20.574 m)
74'6" (22.708 m)
81'6" (24.841 m)
88'6" (26.975 m)
6'9" (2.057 m)
60'8" (18.491 m)
67'8" (20.625 m)
74'8" (22.758 m)
81'8" (24.892 m)
88'8" (27.026 m)
6'11" (2.108 m)
■
If your pin-to-pin headstay length is shown in the chart below use a hacksaw to cut a
special length top foil from a 7' (2.13 m) foil
Cut Top Foil to
This Length
