o Detailed settings when “Assign Mode” is set to
“Dolby Atmos”
When “Assign Mode” is set to “Dolby Atmos”, set the following items.
n Layout
Select the speaker layout for Dolby Atmos playback.
7.1ch + 4 Height:
This is a layout that adds the top front and
top rear speakers to the 7.1 channel layout
which includes the surround back channel.
Connect the top front speakers to the
HEIGHT1 PRE OUT connectors and the top
rear speakers to the HEIGHT2
UNBALANCED RCA PRE OUT connectors
or FRONT WIDE/HIGHT2 BALANCED XLR
PRE OUT connectors.
7.1ch + 2 Height
(Default):
This is a layout that adds the top middle
speakers to the 7.1 channel layout including
the surround back channel. Connect the top
middle speakers to the HEIGHT1 PRE OUT
connectors.
5.1ch + 4 Height:
This is a layout that adds the top front and
top rear speakers to the basic 5.1 channel
layout. Connect the top front speakers to the
HEIGHT1 PRE OUT connectors and the top
rear speakers to the HEIGHT2
UNBALANCED RCA PRE OUT connectors
or FRONT WIDE/HIGHT2 BALANCED XLR
PRE OUT connectors.
5.1ch + 2 Height:
This is a layout that adds the top middle
speakers to the basic 5.1 channel layout.
Connect the top middle speakers to the
HEIGHT1 PRE OUT connectors.
o View Terminal Config.
This shows how to connect the PRE OUT connectors for your “Amp
Assign” setting on the menu screen.
