TASCAM DR-V1HD
39
4 – Video/Audio Recording
PLUG-IN POWER:
Set this to ON when connecting a microphone that requires plug-in
power. Set this to OFF when using the built-in microphone.
Options: ON, OFF (default)
When the INPUT SELECT item is set to LINE, plug-in power will be
disabled regardless of the PLUG IN POWER item setting. When set to MIC,
the PLUG IN POWER item setting will be used.
L/R SWAP:
Set to R-L to switch the left (L) and right (R) channels of the built-in
microphone.
Options: L-R (default), R-L
INPUT TYPE:
Set to STEREO or MONO according to the type of mic being used.
Options: STEREO (default), MONO
When set to MONO, both left and right channels receive the same input
signal.
NOTE
When in recording (video/audio) standby, you can also press the F2 button
(INPUT SETTING) to open the Input Setting screen.
CAUTIONS
If the input signal is too loud, distortion might occur even when the •
LIMITER is ON. If this occurs, lower the recording level manually or move
the recorder further from the sound source.
When connecting a dynamic microphone or a microphone with a built-
•
in battery, set PLUG-IN POWER to OFF. Leaving it ON might damage the
microphone.
Use headphones to monitor when you are recording with a microphone.
•
If you use speakers to monitor, the sound output from the speakers
might also be recorded, causing a poor recording or feedback.
TIPS
If air-conditioning, wind or other noises are being recorded, setting LOW •
CUT to a value other than OFF might reduce the noise.
When recording a live performance or other situation when extremely •
loud signals might be input, set LEVEL CONTROL to LIMITER to prevent
sound distortion due to sudden high levels.
